ABB+DO810 DO801

Description

The ABB DO810 and DO801 are digital output modules used in process control systems, specifically within ABB’s 800xA and AC 800M control systems.

Product Name:

• DO810: Digital Output Module 10 Channels
• DO801: Digital Output Module 8 Channels

Product Description:

• DO810: This module provides 10 digital output channels. It is used for controlling various devices such as valves, motors, and other actuators in automation systems. The output signals can be either energized or de-energized based on the commands from the control system.
• DO801: This module has 8 digital output channels. Similar to the DO810, it is employed in controlling output devices in process control applications. It offers flexibility and reliability for a variety of control tasks.

Product Parameters & Specifications:

• DO810 Parameters:
  • Number of Channels: 10
  • Output Type: Relay or transistor (depends on configuration)
  • Voltage Rating: Typically operates at 24 VDC
  • Current Rating: Specific models may support up to 1 A per channel
  • Output Status Feedback: Available (for monitoring)
  • Isolation: Provides electrical isolation between channels
• DO801 Parameters:
  • Number of Channels: 8
  • Output Type: Relay or transistor (configuration dependent)
  • Voltage Rating: Typically operates at 24 VDC
  • Current Rating: Specific models may support up to 0.5 A per channel
  • Output Status Feedback: Available (for monitoring)
  • Isolation: Provides electrical isolation between channels

Typical Uses:

• Process Control: These modules are designed to control various types of output devices in industrial automation settings.
• Actuator Control: Common applications include controlling valves, motors, and alarms.
• Alarm Systems: Can be integrated into alarm systems for notification and signaling.
• Safety Systems: Utilized in safety-related applications where output control is critical.
• Building Automation: Used in building management systems for controlling HVAC, lighting, and security systems.
