Description

The ABB DO801 module is part of the ABB 800xA distributed control system.

Product Name

ABB DO801 Module

Product Description

The DO801 module is a digital output module designed for use in industrial automation systems. It provides multiple digital output channels for controlling various field devices and equipment. This module is integral to enhancing the flexibility and efficiency of the automation process, allowing for reliable operation in a variety of environments.

Product Parameters

• Input Voltage: Typically 24 V DC
• Number of Outputs: 8
• Output Type: Relay or transistor outputs
• Current Rating: Depends on specific model (often up to 2 A per channel)
• Isolation: Typically galvanically isolated from the backplane

Specifications

• Dimensions: Standard module size (specific dimensions depend on the installation type)
• Operating Temperature Range: Typically -20 °C to +60 °C
• Storage Temperature Range: -40 °C to +85 °C
• Humidity: Up to 95% non-condensing
• Certification: CE, UL, and others depending on the region

Product Use

The DO801 module is commonly used in:

• Process Control: To control valves, actuators, and other field devices in manufacturing and process plants.
• Building Automation: For controlling lighting, HVAC systems, and security devices.
• Infrastructure: Used in utilities for controlling equipment like pumps, motors, and switches.
