Description

The ABB CP450-T-ETH is a touch screen human-machine interface (HMI) designed for industrial applications.

Product Name:

ABB CP450-T-ETH Touch Screen HMI

Product Description:

The ABB CP450-T-ETH is a high-performance touch screen panel designed for easy and intuitive interaction with industrial control systems. It provides operators with an effective interface for monitoring and controlling processes, offering advanced functionality in a compact and rugged design. This model is equipped with Ethernet connectivity, allowing seamless integration into modern industrial networks.

The CP450-T-ETH is ideal for use in environments that require reliable human-machine interaction, such as manufacturing, automation, energy, and other process industries. The product combines a user-friendly interface with robust connectivity and flexible options for integration with ABB and third-party automation systems.

Product Parameters & Specifications:

• Display:
  • Screen Size: 4.3 inches
  • Resolution: 480 x 272 pixels
  • Touch Type: Capacitive touch screen
  • Color Depth: 16-bit color (65536 colors)
  • Brightness: 400 cd/m² (typical)
  • Viewing Angle: 85° horizontal, 85° vertical
• Processor:
  • Type: ARM-based CPU
  • Clock Speed: 600 MHz (or higher)
• Memory:
  • RAM: 128 MB (standard)
  • Storage: 128 MB Flash (expandable via SD card)
• Connectivity:
  • Ethernet: 1 x 10/100 Mbps Ethernet port (RJ45)
  • USB: 1 x USB 2.0 (for data storage and device connection)
  • Serial: 1 x RS-232 / RS-485 (optional)
• Operating System:
  • Platform: Linux-based or proprietary ABB operating system
• Power Supply:
  • Voltage: 24V DC (nominal)
  • Power Consumption: Approximately 5W
• Operating Environment:
  • Temperature Range: -10°C to +60°C
  • Humidity: 10% to 90% non-condensing
  • IP Rating: IP65 (front panel)
• Mounting Type: Panel mount (front bezel with clamp or flush)
• Communication Protocols Supported:
  • Modbus TCP
  • Profinet
  • Ethernet/IP
  • OPC UA
  • MQTT (depending on configuration)
• Compliance & Certifications:
  • CE, UL, RoHS, UL Class 1 Div 2 (depending on variant)

Product Use:

The ABB CP450-T-ETH touch screen HMI is widely used in the following applications:

• Industrial Automation: For monitoring and controlling production lines, machines, and equipment.
• Building Automation: Used in building management systems to control HVAC, lighting, and security systems.
• Energy Management: Provides control and visualization for energy monitoring and distribution.
• Process Control: Used in industries like oil & gas, water treatment, and chemical processing to supervise and optimize operations.
• Remote Control: Allows operators to access and interact with systems remotely via Ethernet or other communication protocols.

Key Features & Benefits:

• Compact & Rugged Design: Suitable for harsh industrial environments with high resistance to dust, moisture, and vibration.
• Intuitive User Interface: The capacitive touch screen allows for easy operation and customization.
• Connectivity Options: Wide range of communication protocols ensures flexibility and integration with various control systems.
• High-Performance Hardware: Ensures smooth operation even in demanding applications.
• Scalability: Can be used in a wide variety of automation systems and easily integrated with other ABB and third-party devices.

This HMI is particularly popular in industries where operators need to monitor multiple parameters in real-time and make adjustments to system operations quickly and efficiently.
