ABB+CI855K01 3BSE018106R1

Description

The ABB CI855K01 is a communication module that is part of the ABB 800xA Distributed Control System (DCS) series. This module plays a crucial role in enabling communication between different components in an ABB control system, ensuring that data and control signals can be exchanged across various devices and systems.

Product Name:

• CI855K01
• Part number: 3BSE018106R1

Product Description:

The ABB CI855K01 is a communication interface module used to interface between the ABB 800xA system and other control systems or devices using standard communication protocols. The module is designed for seamless integration and can connect various types of field devices, such as PLCs (Programmable Logic Controllers), remote I/O systems, or other intelligent devices within industrial control systems.

This module specifically allows communication with other devices over networks such as Modbus, Profibus, and Ethernet/IP, depending on the application requirements. The CI855K01 is often used to enhance the flexibility and expandability of an ABB control system, enabling it to communicate with third-party devices and systems.

Product Features:

• Interface Module: Supports various industrial communication protocols like Modbus, Profibus, and Ethernet/IP.
• High-speed Communication: Ensures fast and reliable data transmission between the system and external devices.
• Flexible Integration: Provides seamless integration with existing systems, allowing ABB DCS to interface with other control systems.
• Scalability: Ideal for applications where scalability is needed to expand or upgrade communication capabilities.
• Redundancy Support: Some versions support redundant configurations for enhanced reliability and uptime.

Product Parameters & Specifications:

• Input Voltage: 24 V DC
• Protocol Support:
  • Modbus RTU/ASCII (RS-485)
  • Profibus DP (RS-485)
  • Ethernet/IP
• Connector Type: Various communication ports (RS-485, Ethernet)
• Communication Speed:
  • Modbus: up to 115200 bps
  • Profibus DP: up to 12 Mbps
  • Ethernet: 10/100 Mbps
• Operating Temperature: Typically between 0°C to 60°C (depending on environmental conditions)
• Power Consumption: Typically 10-15 W (depending on application and configuration)
• Dimensions: Approx. 100mm x 200mm x 60mm (varies with version)

Product Use:

The ABB CI855K01 module is primarily used for industrial automation and control systems in various industries, including:

• Process Control: Connecting sensors, actuators, and other field devices to the control system for process automation.
• Manufacturing Automation: Connecting various machines, PLCs, or other control systems to an ABB DCS for centralized monitoring and control.
• Energy Management: Interfacing with energy meters, power distribution systems, and other energy-related equipment.
• Building Automation: Facilitating integration of building management systems with ABB’s automation platform.
