ABB+CI854AK01 3BSE030220R1

Description

The ABB CI854AK01 3BSE030220R1 is a communication interface module designed for integration into ABB’s automation systems.

Product Name:

ABB+CI854AK01 3BSE030220R1

Product Description:

The ABB CI854AK01 is a communication interface module used in ABB’s Distributed Control Systems (DCS), particularly the 800xA system. This module facilitates the communication between the DCS and external devices or networks using various industrial protocols.

It provides a means of connecting the ABB DCS to field devices, control systems, and other networked equipment, allowing seamless data exchange and control. The CI854AK01 is part of the ABB Advant Controller 400 and is typically used in industries where integrated control and monitoring of processes are critical.

Key Features:

• Protocol support: Supports multiple industrial communication protocols such as Modbus, Profibus, OPC, Ethernet/IP, and more.
• Integration capability: Allows for integration of third-party devices and systems into the ABB automation infrastructure.
• Redundancy support: The module supports redundancy configurations for high availability and system reliability.
• Compact and modular design: Designed to fit easily into the ABB system architecture for efficient space utilization.
• Ethernet connectivity: Uses Ethernet or other standard communication interfaces for easy connectivity to field devices or higher-level systems.

Product Parameters & Specifications:

• Module Type: Communication Interface Module
• Part Number: 3BSE030220R1
• Input/Output Interfaces:
  • Ethernet: Yes, provides communication over standard Ethernet networks.
  • Serial Communication: Multiple serial communication ports for integration with legacy devices.
• Protocol Compatibility:
  • Modbus TCP/IP
  • Modbus RTU
  • Profibus DP
  • Ethernet/IP
  • OPC (for data exchange)
• Redundancy: Supports hot standby for redundancy in critical applications.
• Power Supply: Typically powered by the DCS system with standard voltage requirements (24V DC).
• Environmental Specifications:
  • Operating Temperature: Typically between 0°C to 60°C.
  • Storage Temperature: -40°C to 85°C.
  • Humidity: 5% to 95% (non-condensing).

Product Use:

The CI854AK01 module is used to:

• Facilitate communication between ABB DCS (800xA or Advant Controller) and field devices or other control systems.
• Integrate various industrial protocols into the DCS, making it versatile for different industrial environments.
• Connect to a wide range of devices including sensors, actuators, HMIs (Human-Machine Interfaces), PLCs (Programmable Logic Controllers), and other supervisory control systems.
• Provide redundant communication paths to ensure system uptime and reliability, which is crucial for critical infrastructure operations.

Common Applications:

• Industrial Automation: Used in manufacturing, process control, and energy management systems for efficient data exchange and control.
• Power Generation and Distribution: Used in power plants and substations for integration with SCADA systems, monitoring, and control.
• Oil & Gas: In upstream and downstream facilities for integrating field devices, safety systems, and supervisory control.
• Water Treatment: For controlling and monitoring water purification systems and distribution networks.

ABB+CI854AK01 3BSE030220R1
