ABB+CI854AK01 3BSE030220R1

Description

The ABB CI854AK01 3BSE030220R1 is a communication interface module designed for use in ABB control systems. It facilitates communication between different devices or systems, providing a reliable interface for data exchange.

Product Name:

ABB CI854AK01 3BSE030220R1 Communication Interface Module

Product Description:

The CI854AK01 is part of ABB’s range of communication modules that enable seamless integration of ABB control systems with other automation systems, PLCs, or devices. This module is typically used for fieldbus communication, linking control systems like ABB’s 800xA with other industrial equipment. It supports various industrial communication protocols, offering flexibility and scalability for various applications.

Product Parameters and Specifications:

• Product Code: 3BSE030220R1
• Module Type: Communication Interface Module
• Interface Type: Typically used for connecting controllers and field devices, often including communication over Ethernet, Profibus, Modbus, or other industrial protocols.
• Compatible Systems: 800xA, AC 800M, or other ABB control systems.
• Network Protocols Supported:
  • Ethernet (for connecting with Ethernet-based networks and devices)
  • Fieldbus protocols (such as Profibus, Modbus, etc.)
  • S100/S200 Protocols (depending on configuration)
• Power Supply: 24 V DC (common in ABB modules)
• Operating Temperature: Typically, it operates in the range of 0°C to 60°C (check specific datasheet for exact values).
• Mounting Type: Typically DIN rail mounted.
• Dimensions: Varies, but typical ABB modules are compact for easy integration in control cabinets.
• Protection Class: IP20 (for installation in controlled environments like control panels).
• Status Indicators: Usually has LED indicators for power, network, and communication status.
• Data Transfer Speed: Depending on the communication protocol, data rates can vary. For Ethernet communication, speeds can range from 10 Mbps to 1 Gbps.
• Compliance: CE marked, UL listed, and compliant with relevant industrial standards for safety and electromagnetic compatibility (EMC).

Product Use:

The CI854AK01 module is primarily used in industrial automation settings, particularly for communication between ABB’s 800xA or AC 800M controllers and various field devices. It allows for the integration of different protocols into a single system, which is crucial in complex automation environments that involve different types of equipment, sensors, actuators, and systems from various manufacturers. It enables efficient data flow and control, optimizing system performance and ensuring accurate, real-time monitoring and control.

Common applications include:

• Process Control Systems: Connecting PLCs, sensors, and actuators in industries such as chemical, oil & gas, and power generation.
• Manufacturing Automation: Enabling communication between machine controllers and factory automation systems.
• Building Automation: Integrating heating, ventilation, air conditioning (HVAC), lighting, and other systems into a centralized control system.
• Energy Management: Facilitating communication between meters, controllers, and SCADA systems for monitoring and optimizing energy usage.
