ABB+CI532V05 3BSE007297R1

Description

The ABB CI532V05 3BSE007297R1 module is part of the ABB 800xA distributed control system (DCS) and is commonly used in industrial automation and control applications

Product Name:

ABB CI532V05 3BSE007297R1

Product Description:

The CI532V05 is an input/output (I/O) module designed for use with ABB’s 800xA system, offering a range of digital, analog, and special I/O capabilities to meet the demands of complex industrial environments. This module is typically used to interface field devices (such as sensors, actuators, or other control devices) with the control system, enabling precise data exchange between the field level and the control systems for monitoring and control tasks.

The module features high-speed processing, reliability, and integration with ABB’s DCS and SCADA systems.

Product Parameters and Specifications:

• Module Type: I/O Module (Digital/Analog I/O)
• Series: CI532V05 (part of the CI5xx family)
• Part Number: 3BSE007297R1
• I/O Type: Mixed (Digital and Analog I/O)
• Communication Protocol: Uses the proprietary communication protocol of the ABB 800xA system (based on Ethernet, with high communication speed and reliability)
• Compatibility: Designed to work with ABB’s 800xA system (used in industrial automation systems for a variety of sectors)
• Voltage: Typically operates within 24V DC or 48V DC (depending on the configuration)
• Current Consumption: Varies depending on the specific configuration of the module and connected devices.
• Input/Output Points:
  • Digital Inputs: 16/32 points (depending on configuration)
  • Digital Outputs: 16/32 points
  • Analog Inputs/Outputs: 4 to 8 points (depending on the model configuration)
• Mounting: Can be mounted on standard DIN rail or backplane within the 800xA control cabinet.
• Diagnostics: Extensive diagnostics for monitoring the health of both the module and the I/O devices connected to it.
• Operating Temperature Range: Typically, it supports an operating temperature range of 0 to 60°C.
• Isolation: Galvanic isolation between I/O channels to protect the system from electrical surges and faults.

Product Use:

The CI532V05 module is used in industrial automation systems to connect and manage a wide range of field devices, such as:

• Sensors: Temperature, pressure, flow, or level sensors.
• Actuators: Valves, motors, or other control elements.
• Safety Systems: Integrates with safety instrumentation for shutdowns, alarms, and control.
• Monitoring & Control: Used in the monitoring and control of industrial processes in various sectors, such as oil & gas, chemicals, water treatment, power generation, and manufacturing.
