ABB+CI522A 3BSE018283R1

Description

The ABB CI522A 3BSE018283R1 module is a specific product from ABB designed for use in industrial automation and control systems.

**Product Name:**

ABB CI522A 3BSE018283R1 Module

**Product Description:**

The CI522A module is a communication interface designed to facilitate communication between various field devices and a control system. It acts as an interface between the Control Network and the field devices such as sensors, actuators, and other components in the automation system.

**Product Parameters and Specifications:**

– **Product Type:** Communication Interface Module
– **Part Number:** CI522A 3BSE018283R1
– **Communication Protocol:** Profibus DP-V0/V1
– **Max Number of Nodes:** 124 (limited by the Profibus specification)
– **Operating Voltage:** 24V DC (supplied via the Profibus connector)
– **Communication Rate:** Up to 12 Mbit/s
– **Isolation:** Galvanic isolation between the Profibus DP network and the internal logic

**Product Use:**

The CI522A module is used primarily in industrial automation applications where communication with field devices via Profibus DP protocol is required. It enables the control system to exchange data with sensors, actuators, drives, and other devices distributed throughout the plant or machinery. Typical applications include process automation, manufacturing automation, and machine control systems.

**Key Features:**

– Supports both Profibus DP-V0 and DP-V1 protocols.
– Provides high-speed communication up to 12 Mbit/s.
– Designed for robust industrial environments with galvanic isolation.
– Compatible with ABB’s AC 800M and AC 800PEC control systems.

**Installation and Configuration:**

Installation involves mounting the module on a DIN rail within an enclosure suitable for industrial environments. Configuration typically involves setting parameters such as node addresses and baud rates using configuration software provided by ABB.

This module is crucial for integrating various field devices into a unified control system, ensuring efficient and reliable operation in industrial automation settings.

ABB+CI522A 3BSE018283R1

ABB+CI522A 3BSE018283R1
