ABB+5SHY5055L0002 3BHE019719R0101 GVC736BE101

Description

The ABB 5SHY5055L0002 (3BHE019719R0101) is a power module used in industrial applications, specifically for control and automation systems.

Product Name:

• ABB 5SHY5055L0002 or 3BHE019719R0101 (part number variants)

Product Description:

• This is a power semiconductor module, often part of ABB’s power electronics and industrial automation solutions.
• It’s typically used in frequency converters, drives, and other industrial equipment to manage power conversion, switching, and regulation.
• It is designed for high-efficiency power conversion in industrial applications, helping to improve the performance and energy efficiency of various machinery and systems.

Key Features and Specifications:

1. Type: Power module (often part of an IGBT or MOSFET family)
2. Rated Voltage: Varies by model, typically up to 1200V or higher.
3. Rated Current: The 5SHY series typically offers current ratings in the range of 50-100A, depending on the model.
4. Power Rating: Measured in kW, this can vary based on configuration, usually designed for medium to high power industrial applications.
5. Package Type: Typically comes in a modular package designed for easy integration into power conversion systems.
6. Switching Frequency: These modules are designed for high-frequency switching.
7. Thermal Management: Includes cooling solutions (heat sinks, etc.) for optimal operation.
8. Safety: Built-in protections for overcurrent, overvoltage, and thermal overload.
9. Efficiency: High switching efficiency for reduced energy losses in power conversion processes.

Product Parameters:

• Vces (Collector-Emitter Voltage): ~1200V (depending on the model).
• Ic (Collector Current): Can vary, often in the range of 50-100A.
• Power Dissipation: Dependent on application and duty cycle, but generally designed for high-efficiency operation.
• Package Dimensions: Typically designed for easy mounting in control panels or converters.

Typical Applications:

• Industrial Drives: Used in variable frequency drives (VFDs) to control motor speed and torque.
• Power Inverters: For conversion of DC to AC, used in renewable energy (solar, wind), and other power systems.
• UPS Systems: Uninterruptible power supplies, where high-power switching is essential.
• Welding Equipment: Power regulation in industrial welding machines.
• HVAC Systems: Power management in large heating, ventilation, and air conditioning systems.
• Power Supplies and DC-DC converters: For efficient power conversion and distribution.

ABB+5SHY5055L0002 3BHE019719R0101 GVC736BE101
