ABB+5SHY35L4512

Description

The ABB 5SHY35L4512 is a module from ABB’s range of power electronics and automation components, specifically part of the power semiconductor and drive systems product line.

Product Name:

ABB 5SHY35L4512 Module

Product Description:

The ABB 5SHY35L4512 is a power semiconductor module, typically used in high-power applications where precise control over power is necessary, such as in industrial drives, renewable energy systems, and various automation processes. It is part of ABB’s high-performance IGBT (Insulated Gate Bipolar Transistor) modules, designed for controlling electrical power in AC and DC circuits. The 5SHY series features rugged and reliable semiconductor modules for high-efficiency power conversion and switching.

Product Parameters & Specifications:

• Type: IGBT (Insulated Gate Bipolar Transistor) Module
• Voltage Rating (V_CE): 1200V (This is the maximum voltage the IGBT can handle between collector and emitter)
• Current Rating: 35A (The current the IGBT can handle safely without overheating or damage)
• Package Type: The 5SHY35L4512 is a Dual IGBT Module, commonly used for inverter circuits and motor drives.
• Switching Frequency: Typically capable of switching frequencies up to several kHz, suitable for high-speed switching applications.
• Cooling: Requires an efficient cooling system (liquid or air-based cooling) to manage heat dissipation during operation.
• Modules Structure: Typically uses chopper-type and voltage-controlled designs.

Key Features:

• Low Power Loss: Efficient power switching and minimal loss, enhancing system performance.
• High-Temperature Operation: Designed for operation in harsh environments.
• Fast Switching: Suitable for high-frequency applications.
• Durability and Reliability: Offers a long operational life under continuous stress conditions.
• Comprehensive Protection: Includes thermal, overvoltage, and short-circuit protection to ensure system integrity.

Product Use:

• Motor Drives: Used in industrial motors for controlling speed, torque, and other parameters.
• Power Inverters: Ideal for high-efficiency power conversion in renewable energy systems, like solar and wind power.
• UPS (Uninterruptible Power Supply): Plays a role in providing stable power in critical infrastructure.
• HVDC (High Voltage Direct Current): Used in high-power transmission systems.
• Induction Heating and Other Power Electronics Systems: Optimizes power delivery in industrial heating and process control.

Applications:

• Industrial automation and robotics.
• Renewable energy applications (e.g., wind and solar inverters).
• Uninterruptible power supplies (UPS).
• Electric vehicle (EV) charging stations.
• High-power rectifiers and inverters for high-efficiency grid systems.

ABB+5SHY35L4512
