ABB+3BSE040662R1 AI830A

Description

The ABB AI830A module is a part of the 800xA family and is designed for use in process control applications. It is typically used to interface with analog signals, making it ideal for monitoring and controlling a wide range of process variables.

Product Name:

AI830A Analog Input Module

Product Description:

The AI830A is a compact and high-performance analog input module that provides accurate measurement and acquisition of analog signals. It is designed for use in industrial automation and process control systems and offers reliable performance in demanding environments.

Product Parameters:

– Number of channels: 8
– Input types: Universal analog input (voltage, current, resistance, etc.)
– Input range: Configurable per channel
– Update rate: Configurable

Specifications:

– Operating voltage: 24 VDC
– Analog input range: -10V to +10V, 0-20mA, 4-20mA
– Isolation: 500V AC between channels and backplane
– Accuracy: Better than 0.1% of full scale
– Temperature range: -25°C to +60°C (-13°F to +140°F)

Product Use:

The AI830A module is used to acquire analog signals from field devices such as temperature sensors, pressure transducers, flow meters, and other analog sensors. It interfaces with the control system to provide real-time data for process monitoring, control, and analysis.
