ABB Unitrol 1022 P3BHE030579R0007

Description

The ABB Unitrol 1022 P3BHE030579R0007 is part of ABB’s Unitrol 1022 series, which is a family of excitation control systems used primarily in power generation and industrial applications. This system helps regulate the excitation of synchronous generators, ensuring stable voltage and efficient performance in electrical networks.

Product Name:

ABB Unitrol 1022 P3BHE030579R0007

Product Description:

The ABB Unitrol 1022 series, including the model P3BHE030579R0007, is a static excitation system designed to manage the excitation of synchronous generators. The system is part of ABB’s suite of power control solutions that ensures reliable and efficient generator operation in power plants and industrial facilities. It is particularly focused on providing real-time dynamic voltage regulation, stability, and optimal performance for generators.

This module is likely used for controlling excitation in generators that are part of power plants, industrial installations, or energy distribution systems. The system’s advanced features provide both performance enhancements and operational flexibility for power generation and grid stability.

Product Parameters and Specifications:

The exact specifications can vary based on the version and configuration of the module, but generally, these are the typical characteristics of an ABB Unitrol 1022 excitation system:

• Exciter Type: Static exciter (no rotating parts)
• Control Method: Voltage and power factor control, or dynamic voltage regulation
• Control Loop: Includes automatic voltage regulation (AVR), manual control, and auxiliary control
• Communication Protocols: Typically uses industry-standard communication protocols such as Modbus or Ethernet/IP for integration into control systems
• Input Voltage: Commonly operates on 3-phase AC input voltage, but this varies based on specific models
• Power Output: Can range from several kilowatts to megawatts, depending on the generator size being controlled
• Protection Features: Includes overcurrent, short-circuit protection, and protection for both the exciter and the generator
• Temperature Range: Designed to work in a wide range of operating temperatures (typically -20°C to +50°C)
• Dimensions: Varies, but typically compact for installation in control panels or as part of a rack-mounted configuration
• Mounting: Standard 19-inch rack-mounted or panel-mounted installation options
• Display: Typically includes an integrated HMI (Human-Machine Interface) for configuration and monitoring

Product Use:

The ABB Unitrol 1022 P3BHE030579R0007 module is typically used in:

1. Power Plants: To regulate the excitation of synchronous generators, ensuring stable voltage output, minimizing oscillations, and improving the overall stability of the power grid.
2. Industrial Power Generation: Used in large industrial facilities that use synchronous generators for internal power generation or cogeneration systems.
3. Grid Integration: The system is also used to ensure that generators maintain stable voltage and power factor alignment with grid requirements.
4. Energy Distribution Systems: For ensuring that energy systems remain stable under varying loads and conditions, supporting large-scale electrical distribution.
5. Renewable Energy Systems: Used in conjunction with renewable energy sources (e.g., wind, hydro) to stabilize voltage and power output from synchronous generators connected to these systems.

ABB Unitrol 1022 P3BHE030579R0007
