The ABB SD831 module is part of the ABB’s S800 I/O series, designed for industrial automation and control systems.
Product Name:
ABB SD831
Product Description:
The ABB SD831 is a digital input/output module used in the ABB S800 I/O system. It is designed to provide interfaces for connecting digital field devices like sensors, actuators, and switches to a control system. The SD831 is particularly suitable for harsh industrial environments, offering robust performance and high reliability for industrial automation applications.
The SD831 is part of ABB’s modular and scalable I/O systems, designed to meet the needs of process automation, building automation, and discrete automation applications. It supports a wide range of control and monitoring tasks and is typically used in conjunction with ABB’s automation controllers, such as the AC 800M or AC 800PEC.
Product Parameters / Specifications:
- Module Type: Digital Input/Output
- Number of Channels:
- Digital Inputs: 16 or 32 inputs (depending on the version)
- Digital Outputs: 16 or 32 outputs (depending on the version)
- Input Voltage Range:
- For Digital Inputs: 24V DC (standard)
- For Digital Outputs: 24V DC (standard)
- Signal Type:
- Digital inputs are typically either wet contacts (sourcing) or dry contacts (sinking).
- Digital outputs can be relay-based, or transistor outputs (depending on the version of the module).
- Operating Temperature:
- Typically -20°C to +60°C for standard industrial applications.
- Power Supply:
- The module generally requires a 24V DC power supply.
- Electrical Isolation:
- The SD831 provides electrical isolation between inputs, outputs, and the control system, helping prevent electrical noise and ground loops from affecting the system.
- Communication:
- The module uses Fieldbus communication (e.g., Profibus DP, Ethernet/IP, or Modbus), depending on the specific configuration of the system.
- Mounting:
- The SD831 is designed to be mounted on a DIN rail or directly on a backplane in the S800 I/O system.
- Certifications:
- The module is typically CE marked and may comply with industry standards like UL, CSA, and ATEX for certain hazardous environments.
- Dimensions:
- Vary depending on the specific version and I/O count (typically a modular unit, about 100-150mm in width).
- Diagnostic Functions:
- The SD831 may include diagnostic features such as status LEDs for input/output states, fault conditions, and power status.
Product Use / Applications:
The ABB SD831 module is used in a variety of industrial automation applications where digital I/O capabilities are required, such as:
- Industrial Control Systems: In process control, discrete manufacturing, and factory automation where monitoring and controlling digital field devices like switches, sensors, and actuators are required.
- Building Automation: The SD831 can be used to interface with sensors and devices in building management systems (BMS) for lighting, HVAC, and security systems.
- Process Automation: This module can be used for controlling and monitoring automated processes in chemical plants, water treatment plants, power generation facilities, etc.
- Machine Automation: Used in machine control applications, providing I/O interfaces to manage machine states, alarms, and operator interfaces.
- Energy and Utilities: In utility automation systems for the control of grid infrastructure, energy meters, and distribution panels.
- Remote I/O Systems: In cases where distributed I/O modules are required to be deployed in remote locations, the SD831 can be part of a larger system of modules, reducing wiring and control complexity.
Key Features:
- High reliability and robustness, suitable for harsh industrial environments.
- Easy integration with ABB’s broader automation solutions (AC 800M, AC 800PEC).
- Flexible configuration options for both inputs and outputs.
- Proven communication capabilities with various industrial protocols.
