The ABB REF610 is a protection and control relay designed for medium voltage applications, primarily used in power distribution systems. The specific model REF6103BHB005171R0101 is a variant configured for certain functionalities suited to various engineering applications.
Product Name
ABB REF6103BHB005171R0101
Product Description
The ABB REF610 is a fully integrated protection relay with advanced functionality for medium voltage switchgear. It is designed to provide protection against overcurrent, earth fault, and other fault conditions. The relay can also offer control and monitoring features that help in efficiently managing electrical distribution systems.
Product Parameters and Specifications
- Product Type: Digital Protection Relay
- Communication Protocols: Supports various communication protocols such as IEC 61850, Modbus, etc.
- Inputs/Outputs: Configurable inputs and outputs for flexible integration and application.
- Power Supply: Typically operates on a low-voltage DC or AC supply.
- Operating Temperature Range: Designed to operate under a certain temperature range to ensure reliability.
- Display: May feature an LCD display for user interface.
- Protection Functions:
- Overcurrent Protection (Phase and Earth Fault)
- Voltage Protection (Under/Over Voltage)
- Directional Protection
- Thermal Overload Protection
- Additional Features:
- Event logging
- Fault recording
- Verification tools for relay settings
- Remote monitoring and control capabilities
Product Use
The REF610 relay is widely used in medium voltage applications, including:
- Protection of transformers
- Protection of feeders
- Industrial power distribution systems
- Renewable energy installations (e.g., wind and solar power plants)
- Utility distribution networks
