Product Name:
ABB DO801 – Digital Output Module
Product Description:
The ABB DO801 is a digital output module designed for use in automation and control systems. It is part of the ABB AC500 PLC (Programmable Logic Controller) product family, specifically designed for industrial automation and process control applications. The module provides digital output functionality, allowing users to control external devices such as relays, motors, solenoids, and other actuators based on the control logic in the PLC system.
This module is equipped with multiple channels for output, providing a reliable interface between the PLC and external devices. The DO801 module is particularly suitable for applications that require high-speed switching, high reliability, and the ability to control a variety of industrial equipment.
Product Parameters:
- Number of Channels: Typically 8 digital outputs (varies by configuration)
- Output Type: 24V DC, 0.5A (standard), or 120V AC, 0.5A (depending on model and configuration)
- Output Signal Type: Binary, ON/OFF
- Current Rating per Channel: 0.5A (typically, though this can vary)
- Output Voltage: 24V DC or 120V AC (depending on module version)
- Isolation: Galvanic isolation between channels and the PLC bus
- Signal Type: Sink or Source configuration (depending on model)
- LED Status Indicators: For each output channel to show ON/OFF state
- Connector Type: Screw terminals or spring-loaded terminals for easy installation
- Operating Temperature Range: Typically -20°C to +60°C
- Storage Temperature Range: -40°C to +85°C
- Power Supply: Typically 24V DC for the module’s own power supply
Specifications:
- Dimensions: Varies by model (typically around 120 mm x 80 mm x 70 mm)
- Mounting: DIN rail mount
- Compliance: CE, UL, and other relevant industry standards
- Input/Output Type: Digital (binary) output, compatible with a wide range of devices (motors, relays, alarms, solenoids, etc.)
- Response Time: Fast switching response suitable for most industrial automation needs
- Number of Outputs: 8 (per module, but scalable within the PLC system)
Product Use:
The ABB DO801 digital output module is used primarily in industrial automation systems for controlling digital signals to external devices. Common applications include:
- Control of actuators: Used to control devices like solenoids, motors, valves, and other mechanical systems that require binary control signals.
- Relay control: Suitable for controlling relay modules to switch larger industrial equipment.
- Process Automation: In industries like manufacturing, oil & gas, utilities, and automotive, where digital outputs are needed for machinery control.
- Alarm and Indication Systems: For signaling purposes, such as activating visual or audible alarms when certain conditions are met in the control system.
This module integrates seamlessly with the ABB AC500 PLC system and can be used for both standard and advanced automation tasks, offering flexibility in how digital outputs are utilized across a variety of industrial applications.
