The GE IC693CPU372 is a model of Programmable Logic Controller (PLC) from General Electric’s Series 90-30 family.
Product Name:
GE IC693CPU372
(Also known as GE Fanuc IC693CPU372)
Product Description:
The GE IC693CPU372 is a 32-bit microprocessor-based CPU used in General Electric’s Series 90-30 PLC family. It acts as the central processing unit of a PLC system, executing user-written control programs, managing input/output operations, and communicating with other devices or control systems. The CPU372 offers improved performance, more memory, and enhanced features compared to older PLC models, making it suitable for more complex and demanding industrial control applications.
Product Parameters & Specifications:
- Processor Type: 32-bit Microprocessor (RISC-based)
- Memory:
- RAM: 256KB standard (expandable up to 1MB via memory modules)
- Program Memory: 256KB
- Data Memory: 256KB
- Battery Backup: Optional battery for data retention during power failure
- I/O Compatibility: Compatible with GE Series 90-30 I/O modules and other compatible devices.
- Communication Ports:
- RS-232 Port: For programming and communication with a PC or other systems.
- RS-485 Port: For communication over long distances, typically used for Modbus or other serial communication protocols.
- Local I/O: Interface for connection to Series 90-30 I/O modules.
- Operating System: GE’s proprietary firmware designed for Series 90-30 PLC systems.
- Speed:
- Scan time varies based on the program size and complexity but typically performs faster than earlier models of the Series 90-30 family.
- Battery: Backup battery for memory retention. It can last several years under normal operating conditions.
- Power Supply Requirements:
- Operating Voltage: 5V DC.
- Power Consumption: Approximately 200mA at 5V.
- Mounting:
- Can be mounted on a Series 90-30 rack (IC693) with I/O modules.
- Rack: Up to 10 slots for expansion I/O modules.
- Input/Output:
- Digital and analog I/O modules (not included with the CPU; these must be ordered separately).
- Operating Temperature Range:
- 0°C to 60°C (32°F to 140°F).
- Storage Temperature Range:
- -40°C to 85°C (-40°F to 185°F).
- Weight: Approx. 1.2 kg (2.65 lbs).
- Dimensions:
- Height: 5.5 inches (140mm)
- Width: 3.25 inches (83mm)
- Depth: 5 inches (127mm)
Product Use:
The GE IC693CPU372 is primarily used in industrial automation and control applications, including:
- Manufacturing Automation: It controls processes in manufacturing lines, assembly stations, packaging, and material handling systems.
- Machine Control: The CPU372 is used in automated machinery, from simple machines to complex robotic systems.
- Process Control: It supports complex, continuous process control systems, like those in the oil, gas, chemical, and water treatment industries.
- Remote Monitoring and Control: The CPU372 can be integrated into SCADA (Supervisory Control and Data Acquisition) systems for real-time remote control.
- Building Automation: Managing HVAC (Heating, Ventilation, and Air Conditioning) systems, lighting, and security systems in large buildings or campuses.
- Energy Management: Used in controlling and monitoring energy usage, ensuring efficient operation of power systems or industrial facilities.
- Communication Systems: The communication ports (RS-232, RS-485) allow the CPU372 to interface with various communication protocols like Modbus, Profibus, and others.
